Gravely ZT XL 60 - 24hp Kawasaki FR730V, w/60 Fabricated X-Factor Deck, ZT-2800 Transaxles, Seat Isolation 918016
Gravely ZT XL 60 - 24hp Kawasaki FR730V, w/60 Fabricated X-Factor Deck, ZT-2800 Transaxles, Seat Isolation 918016
Gravely ZT XL 60 - 24hp Kawasaki FR730V, w/60 Fabricated X-Factor Deck, ZT-2800 Transaxles, Seat Isolation 918016

Gravely ZT XL 60 - 24hp Kawasaki FR730V, w/60 Fabricated X-Factor Deck, ZT-2800 Transaxles, Seat Isolation 918016

SKU: ZT XL 60 - 24hp Kawasaki FR730V, w/60 Fabricated X-Factor Deck, ZT-2800 Transaxles, Seat Isolation 918016-918016
Categories : Ariens/Gravely
Out of Stock
Regular price$5,599.00
Sold out

Description:

Built for big jobs, the ZT XL has been redesigned with vibration isolators and a high-back seat to combine professional cut quality and comfort. Out-maneuver any obstacle with more deck sizes to meet your demands.

Specification:

Model Number: 918016

Power Train

  • Engine: Kawasaki® FR730V
  • Horsepower: 24 HP
  • Engine Displacement: 44.3 in³ / 726 cc
  • Fuel System: Gas
  • Fuel Capacity: 3.5 gal / 13.2 ltr
  • Drive System: Hydro-Gear® ZT-2800® Transaxles
  • Transmission Type: Hydrostatic
  • Brake Type: Integrated Parking Brake
  • Driver Position: Sit
  • Ground Speed Forward: 7 mph / 11.3 kph
  • Ground Speed Reverse: 3 mph / 4.8 kph

Wheels

  • Front Wheels: 11.0 x 6.0 in - 5.0 in (27.9 x 15.2 cm - 27.9 cm)
  • Rear Wheels: 20.0 x 10.0 in - 8.0 in (50.8 x 25.4 cm - 20.3 cm)

Electric

  • Battery Capacity: 190 CCA
  • Number of Batteries: 1
  • Battery Voltage: 12 V
  • Battery Type: AGM
  • Battery Size: U1 Compatible

Deck

  • Deck Size: 60 in / 152.4 cm
  • Coverage per Hour: 4.2 acres / 1.7 hectares
  • Spindle Type: Mechanical
  • Deck Material: 11 ga
  • Deck Construction: Fabricated X-Factor®
  • Discharge Configuration: Side
  • Cutting Height Minimum: 1.5 in / 3.8 cm
  • Cutting Height Maximum: 4.5 in / 11.4 cm
  • Cutting Width: 60 in / 152.4 cm

Dimensions

  • Weight (Assembled): 725 lb
  • Length: 74.5 in / 189.2 cm
  • Width (Chute Up): 63.1 in / 160.3 cm
  • Width (Chute Down): 74.2 in / 188.5 cm

Width Weight Height Length
  725 Pounds   74.5 Inch
